STATE-OF-THE-ART TECHNOLOGY
Machine learning algorithms. Self-learned classification
INCREASE PRODUCTIVITY
High throughput & automated processing. Instant data recording.
SEAMLESS INTEGRATION
IR 4.0 Ready. Customizable to existing workflow.
CONSISTENT RESULTS
100% QC check eliminate human errors.
Key Features
Object Counting |
|
|
Count the number of sample in seconds, support major camera system available on market. Support customization and can easily be integrated to any process, machine or equipment. |
|---|---|
Offset Measurement |
|
|
|
User configurable tolerance for the inspected parts. Overall results are available in a glance. |
|---|---|
Template Matching |
|
|
|
An efficient solution for QC test with the capability of setting golden sample for similarity comparison within seconds. The system equipped with easy to read "PASS" & "FAIL" indication, clear message for process owner to judge. |
|---|---|
Smart Defect Detection |
|
|
|
Simple and ease setup with user-configurable tolerance for the inspected parts. Capable of detecting defects that are complex in nature within seconds and the overall results are available in a glance. |
|---|---|
Smart AI Vision
Product Information
Model |
AIV Object Counting |
AIV Offset Measurement |
AIV Template Matching |
AIV Advanced Defect Detection |
|---|---|---|---|---|
| Key Features | An efficient solution for QC test with the capability of setting golden sample for similarity comparison within seconds | Simple and ease setup with user configurable tolerance for the inspected parts. Offset measurement up to 0.01mm within seconds and the overall results are available in a glance. | Simple and ease setup with user configurable tolerance for the inspected parts. Automatically count objects within seconds and the overall results are available in a glance | Simple and ease setup with user configurable tolerance for the inspected parts. Capable of detecting defects that are complex in nature. within seconds and the overall results are available in a glance. |
| Hardware Configuration | 1.3 MP Mono Color Camera | 1.3 MP Mono Color Camera | 1.3 MP Mono Color Camera | Dell AI Workstation (i3) |
| 6mm Lens | 16mm Lens | 16mm Lens | Dell Monitor | |
| Model L Adjustable Mounting Kit |
Model M Adjustable Mounting Kit |
Model M Adjustable Mounting Kit |
5 MP Mono Color Camera |
|
| Telecentric Lens | ||||
| Model M Adjustable Mounting Kit | ||||
| Client Software | Smart Object Counting | Smart Offset Measurement | Smart Template Matching | Smart Advanced Defect Detection |
| Operating System | Linux | Linux | Linux | Linux |
| Working Temperature | 0 °C to 50 °C | 0 °C to 50 °C | 0 °C to 50 °C | 0 °C to 50 °C |
| Humidity | 20% to 80% RH, without condensation |
20% to 80% RH, without condensation |
20% to 80% RH, without condensation |
20% to 80% RH, without condensation |
| Dimension | 480 (L) * 360 (W) * 608(H) mm | 260 (L) * 200 (W) * 392(H) mm | 260 (L) * 200 (W) * 392(H) mm | 260 (L) * 200 (W) * 392(H) mm |
| Weight | 10kg | 8kg | 8kg | 8kg |
| Region of Interest | 250 (L) * 320 * (W) * 25 (H) mm | 80 (L) * 80 * (W) * 40 (H) mm | 80 (L) * 80 * (W) * 40 (H) mm | 80 (L) * 80 * (W) * 40 (H) mm |
| Operating Voltage | 5.1V DC | 5.1V DC | 5.1V DC | 240V AC |
| Operating Current | 3.0 A | 3.0 A | 3.0 A | 8.0 A |
| Sensor | 1.3 MP, 1/3" CCD, Area Scan Mono Camera |
1.3 MP, 1/3" CCD, Area Scan Mono Camera |
1.3 MP, 1/3" CCD, Area Scan Mono Camera |
5.0 MP 2/3" CMOS USB 3.0 Mono Camera |
| Pixel Size | 3.75 µm* 3.75 µm | 3.75 µm* 3.75 µm | 3.75 µm* 3.75 µm | 3.45 μm * 3.45 μm |
| Resolution | 1280 * 960 pixel | 1280 * 960 pixel | 1280 * 960 pixel | 2448 * 2048 pixel |
| Max. Frame Rate | 30 frame per second (fps) | 30 frame per second (fps) | 30 frame per second (fps) | 35 frame per second (fps) |
| Exposure Time | 10 μs to 1 s | 10 μs to 1 s | 10 μs to 1 s | 50 μs to 10 s |
